hophop 500

product specifications

Pure, simple, cylindrical forms of variable sizes and positioned at customizable heights and distances invite passers-by to sit, rest, play – and jump!

Inspired by low tree stumps, the game ”Don’t touch the ground!” and the possibility of varied elements in the land- and cityscape.  Simplicity and variety; pure, simple, cylindrical forms of variable sizes and positioned at customizable heights and distances invite passers-by to sit, rest, play – and jump!

TECHNICAL DATA



Material


Rotation moulded polyethylene, 6-7 mm thick, dyed. Moulded in one piece. UV-resistant, stands up to weather, wear and tear. The material is suitable for granulation and recycling.



Surfaces and friction
The products have a textured/granulated surface due to abrasive blasting of the mold. This process enhances the friction and makes the surface less slippery.



Certifications

TÜV approved as playground equipment acc. EN1176.



Dimensions
Ø500 x H400mm
Volume: 70L

Fixation
For surface and ground fixation. Brackets to be ordred separately.
HopOp500 can also be filled with sand or water and placed directly on the ground.



Maintenance
This product withstands most cleaning agents and chemicals and can be cleaned using a high-pressure cleaner. The colour can be revived using vinyl cleaner or similar



Product code


141 0101 HopHop red              9 kg / 19.8 lbs

141 0102 HopHop limegreen   9 kg / 19.8 lbs

141 0103 HopHop orange        9 kg / 19.8 lbs

141 0104 HopHop yellow         9 kg / 19.8 lbs

141 0109 HopHop purple         9 kg / 19.8 lbs

141 0111 HopHop sandstone   9 kg / 19.8 lbs

141 0113 HopHop grey             9 kg / 19.8 lbs

141 0117 HopHop blue             9 kg / 19.8 lbs

141 0115 HopHop pastel blue  9 kg / 19.8 lbs

141 0116 HopHop brown          9 kg / 19.8 lbs

141 0118 HopHop olive green  9 kg / 19.8 lbs

141 0150 HopHop white           9 kg / 19.8 lbs

Tender


A functional bollard for sitting or jumping
Material: Rotation moulded polyethylene, 6 mm thick, dyed.
Dimensions: Ø500 + H400mm.
Fixation: For surface and ground fixation





STANDARD COLORS   (Approx RAL)



red              RAL 3020

limegreen   RAL 120 70 60

orange        RAL 2003

VARIANT COLORS        (Approx RAL)

yellow         RAL 1018

purple         RAL 4004

sandstone

grey            RAL 7015

blue            RAL 5010

pastel blue  RAL 5024

brown          RAL 8028

olive green  RAL 6025

white           RAL 9003
